Batching Plant Pan Mixer Type
(AP Series)

Home » Batching Plant » Fully Automatic Concrete Batching & Mixing Plant ( AP series )

Fully Automatic Concrete Batching & Mixing Plant (AP Series)

AP Series is dedicated to concrete batching and mixing plant with Pan Mixer. This is the economical series. This is the economical series having the benefits of Pan Mixing Technology Low Polishing, Fast mixing and low noise are the basic features that makes it special.

Batching Plant Pan Mixer Type (AP Series)

Ask for Price

Technical Specification :

Model	AP-30	AP-45
Capacity (Cum! Hr)	30	45
Geo. Volume (Cum)	1.7	2.5
RMC out put /Batch	0.5 M3	0.75 M3
% of Filling	40.00%	40.00%
Batches Per Hour	60	60
Discharge Height From G.L	Discharge in TM	Discharge in TM
Capacity ( 8 Hours)	240 M3	360 M3
Boom Scrapper	In Built	In Built
Discharge Gate Opening System	Hydraulic	Hydraulic

Power Consumption :

Model	AP-30	AP-45
Pan Motor	30 HP	40 HP
Skip Motor	10 HP	15 HP
Screw Feeder Motor	15 HP	15 HP
Scrapper Motor	10 HP	15 HP
Water Pump	2 x 5 HP	2x5 HP
Compressor Motor	5 HP	5 HP
Chemical Motor	3 HP	1HP
Vibrators	2 x 1 HP	2 x 1 HP
Power Pack Motor	3 HP	3 HP
Power Supply	415 x 30 x 50 Hz	415 x 30 x 50 Hz
Recommended DG Set	110 KVA	125 KVA

Technical Features :

PLC operated completely automatic control panel.
Blade mixing technology with planetary gear-boxes.
Electronic weighing system for better accuracy in design – mix.
Separate weighing system for cement and fly-ash.
Italian screw feeder, to pour cement speedily
Password locking facility
Water and ad-mix pour by weight.
Boom scrapper to make you work easier.
Pneumatically weighing system for cement and fly-ash.
Italian vibrators.
Tabulated print out system for each batch.
No pit required only nominal civil work.
Heat proof control cabin.
Cement silo with vertical screw feeder (optional)
Hydraulic discharge system.
E-mail or SMS facility (optional)
